moto g5 plus stock rom

Welcome to Gammerson.com, in this tutorial we are going to teach you how to install stock rom in Moto G5 plus and unbrick and fix bootloop. Recently moto has launched this device. In 2 variants one is G5 plus and moto g5, one is 16gb with 3gb of Ram and 2nd is 32gb with 4gb of Ram. This phone has good battery backup you will get the battery for 1 day with normal usage. Motorola is now owned by Lenovo. So you will the Lenovo branding in your Moto Device.

moto g5 plus stock rom

What is Stock Rom?

Stock Rom means that a device having pre-installed rom or from the manufactured place.

Why people need to install stock rom? Because they install custom and they are very buggy so they want there stock rom back. So, in this guide we are going to install stock rom in Moto G5 plus. Steps are very easy, don’t worry about that. If get any trouble just ask us in comment box.

Disclaimer

Gammerson.com is not responsible for any damage cause to your mobile during the process. DO IT AT YOUR OWN RISK. you how to install stock rom in Moto G5 plus.

Pre-Requirements

Make sure your phone is charged up to 80%

Make the Backup of important apps, messages, and contacts.

Do not try this guide on any other android device.

Download Stock Rom in Moto G5 plus

1.Moto G5 plus stock rom

2. Download Motorola Drivers

3.Minimal Adb fastboot Drivers

Steps to install stock rom in Moto G5 plus

1.Download Moto G5 and G5 Plus Stock Firmware from bottom of this page.

2.Now install Motorola Driver and ADb Fastboot driver on the desktop.Then extract stock firmware in the ADB fastboot folder.

3.Now Press Shift and Right click any where in the ADB fastboot folder and Click on open command prompt here.

4.Now Turn Of your device and turn on by pressing volume down button and Power button simultaneously until you boots into Bootloader as like below image.

5.Then Connect your device with your computer via usb cable.

  1. Now Type the following command One by one in the command prompt.

mfastboot oem fb_mode_set
mfastboot flash partition gpt.bin
mfastboot flash bootloader bootloader.img
mfastboot flash logo logo.bin
mfastboot flash boot boot.img
mfastboot flash recovery recovery.img
mfastboot flash dsp adspso.bin
mfastboot flash oem oem.img
mfastboot flash system system.img_sparsechunk.0
mfastboot flash system system.img_sparsechunk.1
mfastboot flash system system.img_sparsechunk.2
mfastboot flash system system.img_sparsechunk.3
mfastboot flash system system.img_sparsechunk.4
mfastboot flash system system.img_sparsechunk.5
mfastboot flash system system.img_sparsechunk.6
mfastboot flash system system.img_sparsechunk.7
mfastboot flash modem NON-HLOS.bin
mfastboot erase modemst1
mfastboot erase modemst2
mfastboot flash fsg fsg.mbn
mfastboot erase cache
mfastboot erase userdata
mfastboot erase customize
mfastboot erase clogo
mfastboot oem fb_mode_clear
mfastboot reboot

7.One done you have succesfully installed Stock rom in your Moto G5 plus or unbrick your device

If you find any problem regarding this, please let me know in the comment Box

Hope you like this article.

1 COMMENT

  1. some of the commands gave me errors, for example sparse 5,6, and 7 were non existant. the splash screen with the unlock warning still comes up and it is still changed from n/a to bad on the ID, however it did not get stuck there this time. my phone actually booted after the last command, meaning I’m definitely a step or two closer. Now I need to figure out how to relock the bootloader to avoid receiving that message I’m guessing?
